| Engine make/model: |
Lyc. O-360-A4K |
| Horsepower: |
180 |
| TBO: |
2000 |
| Propeller: |
Const. spd. |
| Landing gear type: |
Tri/Fixed |
| Gross weight (lbs.): |
2400 |
| Empty weight (lbs.): |
1294 |
| Useful load (lbs.): |
1106 |
| fuel (gals.): |
51 |
| Wingspan: |
31.5 ft. |
| Overall length: |
22 ft. |
| Height: |
8 ft. |
| Wing area (sq. ft.): |
140 |
| Seating capacity: |
4 |
| Cabin width (in.): |
40 |
| Cabin height (in.): |
45 |
| Baggage capacity
(lbs.): |
120 |
|
PERFORMANCE
|
| Cruise speed (knots): |
| 75% power: |
139 |
| 65% power: |
131 |
| Max range (with
reserve) (nm): |
| 75% power: |
552 |
| 65% power: |
578 |
| Fuel consumption (gph): |
| 75% power: |
10.8 |
| 65% power: |
9.7 |
| Estimated endurance |
| (65% power with 1-hr.
reserve): |
| 4 hrs. 30 mins. |
| Stall speed (gear,
flaps down) |
| (knots): |
53 |
| Best rate of climb (fpm): |
850 |
| Service ceiling (ft.) |
13,850 |
| Takeoff ground roll
(ft.): |
865 |
| Landing ground roll
(ft.): |
410 |
|
